Uni-Drive Poly-Ribs Belt
Uni-Drive Poly-V Belts, also known as Poly-Ribbed Belts, are precision-engineered, continuous multi-ribbed belts designed for compact, high-performance power transmission. They combine the flexibility of flat belts with the strong grip of V-belts, delivering smooth, quiet, and efficient operation even under demanding conditions.
These belts are used across a wide range of applications — from automotive systems (alternators, power steering pumps, water pumps, and A/C compressors) to industrial equipment, HVAC systems, and heavy machinery requiring stable, high-speed power delivery.
Design & Construction
Each Uni-Drive Poly-V Belt features high-strength polyester tensile cords and precision-moulded ribs running longitudinally along its length. This ribbed design ensures consistent load distribution, superior flexibility, and reduced slippage. The compact cross-section allows operation on small pulley diameters, long centre distances, and high transmission ratios — up to 30:1 or higher — with minimal vibration or noise.
A single multi-rib belt can replace several matched conventional belts, simplifying installation and maintenance while saving space. The design also supports idler pulleys and automatic tensioners, maintaining optimal belt tension and alignment with minimal stretch over time.
Key Features
-
High power transmission efficiency in a compact layout
-
Suitable for small pulley diameters and long centre distances
-
Operates at linear speeds up to 60 m/sec
-
Highly flexible, anti-static, oil- and heat-resistant construction
-
Smooth, vibration-free, and noise-free performance
-
Reliable under speed ratios up to 1:30
-
Temperature range: –25 °C to +100 °C
-
Available profiles: PH, PJ, PK, PM, DPK, L
Product Showcase
FRAS (Fire resistant, Anti-Static)
Also Available in FRAS (Fire resistant, Anti-static)
FRAS Product Range: Sections: PJ, PK, PL, PM
Features: Fire resistant, antistatic, electrical resistance values are most stringent than ISO 1813, fulfills requirement according to pr-EN 13464-5:2003 & ISO 9563:1990, ATEX certified
Temperature range: -25ºC to +100ºC
Applications: Coal mines, fire prone areas, petrochemical installations etc.
ATEX Certified
Also available in HIGH TEMPERATURE BELTS
High temperature Product Range: Sections: PJ, PK, PL
Features:
• Temperature range: -35ºC to +130ºC
• High temperature resistant
• Longer service life
• Crack & damage free in high temperature applications
Also Available in DOUBLE SIDED POLY-RIBBED BELTS
Double sided Product Range:
Sections:
DPK: 2 to 22 ribs – DPK Section length: 1195 mm to 3105 mm
DPL: 2 to 22 ribs – DPL Section length: 1200 mm to 3105 mm
Temperature range: -25ºC to +100ºC
Applications: High speed engines, serpentine drives, textile machineries etc.
Also available in ELASTICATED Poly-Ribbed BELTS
Section: EL -PJ : 2 to 20 ribs
Range: 356mm to 2240mm
Features: Belt with elastic properties
Temperature range: -25ºC to +100ºC
Applications: Washing machine & dryers.
Also available TOPCOATED Poly-Ribbed Belt for Packaging Machinery
Features:
• Profile top rubber, specific to applications
• Facilitates excellent cushioning coupled with extra elasticity
• Excellent flexibility to prevent cracks or tearing
• Optimum friction suitable for providing proper support to contact material
• Vulcanized as a single piece to ensure excellent adhesion
• Abrasion resistant
• Longer life
• Top profile thickness: 1.5mm, 3mm, 6mm, 8mm & 10mm
Temperature Range: -18ºC to +80ºC
Product Range:
PJ: up to 36 ribs, Length: 700 mm to 2000 mm
PK: up to 24 ribs. Length: 700 mm to 2000 mm
PL: up to 18 ribs. Length: 700 mm to 2000 mm
Application:
FFS (Form-fill & seal) machine, bakery, paper & printing, soaps & cosmetics, cable-drawing, plastic tube drawing, bottling plants etc
Note:
1. Belt selection should strictly be done on the basis of temperature, top coat hardness & application
2. Availability of a particular size in product range to be cross checked before placing the order
