TAPER-BUSHING AND ALUMINIUM TIMING PULLEYS

Timing drives HTD®, GT®, GT2®, GT3® and POLY CHAIN® GT2, POLY CHAIN® GT CARBON

MXL, XL, L, H, XH, XXH profile also available.

HTD – 03M PITCH 10 TO 72 TEETH,     HTD – 05M PITCH 12 TO 72 TEETH
HTD – 08M PITCH 22 TO 192 TEETH,   HTD – 14M PITCH 28 TO 264 TEETH
HTD – 20M PITCH 34 TO 264 TEETH

Some of the benefits of using industrial timing belts;

High mechanical efficiency, as much as 98% when properly maintained. By contrast, chain drives are in the 91-98% efficiency range, while V-Belts average in the 93-98% range. Power transmission efficiency is not lost by use of timing belts, Clean operation, no need for lubrication., reduced noise, Rust Corrosion.

Aluminum Timing Pulley

T2.5 PITCH TIMING PULLEY
T05 PITCH TIMING PULLEY
T10 PITCH TIMING PULLEY
T20 PITCH TIMING PULLEY

BAR FORM ALSO AVAILABLE

AT05 PITCH TIMING PULLEY
AT10 PITCH TIMING PULLEY
AT20 PITCH TIMING PULLEY

BAR FORM ALSO AVAILABLE
